They range from simple installations to complex, high-performance networks with comprehensive management functions and extremely high failure tolerance.
#Hirschmann switch rs20 mac
3.5 mm, 3 Hz-9 Hz, 10 cycles, 1 octave/min.Product FeaturesFast and simple selection of features using the web configurator and drop-down listsVersions with 4 to 25 Fast Ethernet portsConvenient configuration and diagnostics thanks to comprehensive management functions (serial interface, web interface, SNMP V1/V2, HiVision File Transfer, SW, HTTP/TFTP, LLDP-MED)High network availability owing to fast redundancy protocols (HIPER Ring, MRP, MSTP, RSTP-IEEE802.1D-2004, MRP and RSTP in parallel, Link AggregationHigh data security thanks to numerous security mechanisms (IP and MAC Port Security, SNMP V3, SSHv2, Authentication (IEEE802.1x), 802.1x Multi Client Authentication, Guest VLAN and Unauthenticated VLAN, Port based Radius VLAN Assignment, Login Banner)ApplicationsIn the automation area, the demands made on data communication via Ethernet differ widely from application to application. STEP7, or Control Logixįlow control 802.3x, port priority 802.1D/p, priority (TOS/DIFFSERV)ġ mm, 2 Hz-13.2 Hz, 90 min.
#Hirschmann switch rs20 software
QoS 4 classes, port priorisation (IEEE 802.1D/p), VLAN (IEEE 802.1Q), shared VLAN learning, multicast (IGMP Snooping/Querier), multicast detection unknown multicast, broadcast limiter, fast agingĮtherNet/IP and PROFINET (2.2 PDEV, GSDML stand-alone generator, automatic device exchange) profiles included, configuration and diagnostic via automation software tools like e.g.
HIPER-ring (ring structure), MRP (IEC-ring functionality), RSTP 802.1D-2004, redundant network/ring coupling, MRP and RSTP in parallel, redundant 24 V power supply Port Security (IP und MAC) with multiple addresses, SNMP V3 (no encryption) LEDs, log-file, relay contact, RMON, port mirroring 1:1, topology discovery 802.1AB, address conflict detection, network error detection, SFP diagnostic, Trap for configuration saving and changing, duplex mismatch detection, disable learning.Ĭommand line interface (CLI), TELNET, BootP, DHCP, DHCP option 82, HIDiscovery, easy device exchange with auto-configuration adapter ACA21-USB (automatic software and/or configuration upload), automatic invalid configuration undo, configuration signature (water marking)
#Hirschmann switch rs20 serial
Serial interface, web interface, SNMP V1/V2, HiVision file transfer SW HTTP/TFTP
Ring structure (HIPER-Ring) quantity switchesġ2/24/48 V DC (9,6-60) V and 24 V AC (18-30) V (redundant)
This DIN-Rail switch offers redundancy solutions and can provide network supervision in process and traffic automation.ġ x USB to connect the AutoConfiguration Adapter ACA21-USBĠ - 5000 m, 8 dB link budget at 1300 nm, A = 1 d/km, 3 dB reserve, B = 800 MHz x kmĠ - 4000 m, 11 dB link budget at 1300 nm, A = 1 dB/km, 3 dB reserve, B = 500 MHz x km As part of the configurable OpenRail Ethernet group, RS20-0800M4M4SDAE is ideal for those who need exact specifications. The Hirschmann RS20-0800M4M4SDAE (P/N: 943434-017) is a managed industrial Fast Ethernet Switch featuring store and forward switching mode, a fanless design, 6 x 10/100Base-TX RJ45 sockets, 2 x 100Base-FX multimode ST fiber ports & Layer 2 Enhanced software.
